Effect on Long-time Survival for Different Tumor Volume in Stage Ⅲ Non-small Cell Lung Cancer after Three Dimensional Conformal Radiotherapy
-
摘要: 目的 分析肿瘤靶体积大小对Ⅲ期非小细胞肺癌（NSCLC）三维适形放疗（3D-CRT）长期疗效的影响。方法 收集2000年8月—2004年12月行三维适形放疗的72例Ⅲ期NSCLC患者资料。其中，ⅢA期29例、ⅢB期43例。单纯放疗32例、放疗联合化疗40例；采用前程常规+后程三维适形放疗者28例、全程三维适形放疗者44例；中位等效生物剂量6 625 cGy(范围5 000~7800 cGy)。采用剂量体积直方图（DVH）计算肿瘤靶体积（GTV）、临床靶体积（CTV）、计划靶体积（PTV）。放射性肺炎和放射性食管炎采用RTOG标准评价。结果 随访5年，随访率95.8%。放疗后CR 14例、PR 42例、SD 16例，1、3、5年总生存率及中位生存期分别为45.8%、15.3%、10.5%和10.2月 。按照GTV中位值155 cm3分为两组，只有GTV＞155 cm3组2级以上放射性肺炎发生率高（P＜0.05）；而性别、年龄、T、N、TNM、等效生物剂量、照射方式、化疗、近期疗效和放射性食管炎，两组间分别比较，差异无统计学意义（P＞0.05）。GTV≤155 cm3和＞155 cm3放疗后1、3、5年生存率和中位生存期分别为61.1%、19.4%、16.2%、17月和30.6%、11.1%、4.2%、9月（χ2=5.16，P=0.023）。CTV和PTV按照中位值分两组，两组间生存率的比较差异均有统计学意义（P＜0.05）。全组预后单因素分析显示GTV、CTV、PTV、近期疗效（CR+PR/SD）与预后生存有关（P＜0.05）；多因素分析显示GTV和近期疗效是独立预后因素。结论 肿瘤靶体积大小是影响Ⅲ期非小细胞肺癌放疗预后的重要因素，近期疗效也影响预后生存。Abstract: Objective To explore the effects of tumor volume on long-time effi cacy of stage Ⅲ non-small cell lung cancer (NSCLC) after three dimensional conformal radiotherapy (3D-CRT). Methods From August 2000 to December 2004, 72 patients, 29 cases were in ⅢA and 43 cases in ⅢB stage. 32 cases were treated with radiotherapy alone, while 40 cases with concurrent or sequential radiotherapy and chemotherapy. 28 cases were treated with conventional radiotherapy (CRT) and later-course 3D-CRT, while 44 cases with 3D-CRT. The median equivalent dose was 6 625 cGy(5 000-7 800 cGy). DVH was used for assessing GTV, CTV and PTV.Standard of RTOG Radiation was used for evaluating induced esophagitis and pneumonitis. Results 69 cases were followed up for 5 years and rate was 95.8%. After radiotherapy, there were 14 cases of CR, 42 cases of PR, and 16 cases of SD. Overall survival rate and median survival time of 1 year, 3 years, and 5 years was 45.8%, 15.3%, 10.5% and 10.2 months, respectively. All patients were divided into two groups according to GTV median (155 cm3). Only the incidence of ＞grade 2 radiation induced pneumonitis in group of GTV＞155 cm3 was higher than that in group of GTV≤155 cm3 (P<0.05), while there was no significant difference in gender, age, T, N, TNM, biologic equipotent dose, radiation style, chemotherapy and radiation esophagitis between two groups. Overall survival rate and median survival time of 1 year, 3 years and 5 years of patients with GTV≤155 cm3 and ＞155 cm3 were 61.1%, 19.4%, 16.2%, 17 months and 30.6%, 11.1%, 4.2%, 9 months respectively(χ2=5.16, P=0.023). CTV and PTV were divided into two groups according to median, and there was signifi cant difference in survival rate (P<0.05). With univariate analysis of all prognosis, GTV, CTV, PTV, and immediate effect were related with prognostic survival (P<0.05). Multivariable analysis indicated GTV and immediate effect were independent prognostic factors. Conclusion GTV was one important prognostic factor for stage III NSCLC after 3D-CRT, and immediate effect was another prognostic factor.
-
0 引言
淋巴管浸润和淋巴结转移是结直肠癌患者预后较差的重要原因之一，新生淋巴管是肿瘤淋巴道转移的基础和前提[1-2]。DNA结合分化抑制蛋白1（inhibitors of DNA binding-1,Id-1）是近年来研究较热门的致癌基因，能促进细胞增殖，诱导肿瘤血管内皮生成，促进肿瘤的生长及侵袭，其表达的缺失、沉默与肺癌、胃癌、胰腺癌、宫颈癌等多种恶性肿瘤发生、发展及预后密切相关[3-6]。MMP-9能够降解细胞外各型胶原、层粘连蛋白、蛋白聚糖等，诱导肿瘤细胞突破基底膜致其浸润，参与肿瘤脉管形成[7-8]。D-240特异性表达于肿瘤微淋巴管细胞,在血管内皮细胞中几无表达，因而D-240能准确监测癌组织内的微淋巴管密度（lymphatic microvessel density,LMVD），反映肿瘤淋巴管新生状况。本实验通过对结直肠癌组织中Id-1、MMP-9和LMVD行免疫组织化学分析，探讨三者与结直肠癌临床相关病理的联系及其相关性,为探索结直肠癌演进、淋巴结转移的机制及抗淋巴管浸润治疗提供科学依据。
1 资料与方法
1.1 资料来源
收集2013年5月1日—2014年5月31日河北北方学院附属第一医院血管腺体外科手术切除的原发性结直肠癌组织50例、癌旁正常组织50例，癌组织取自癌灶中心处，另取标本残端切缘经病理证实的正常结直肠组织，术前均未行新辅助放化疗等针对性治疗。其中男32例、女18例，年龄33~71（51±2.9）岁。
1.2 免疫组织化学染色方法及试剂
兔抗人单克隆浓缩型Id-1抗体、鼠抗人浓缩型MMP-9单克隆抗体均购于英国Abcam公司；D-240抗体购于美国Abnova公司。10%甲醛溶液固定部分标本，石蜡包埋，切片厚度为4 µm，苏木精-伊红（hematoxylin-esin,HE）染色，80℃烤箱烤片，乙醇脱水，灭活内源性过氧化物酶，枸橼酸缓冲液高温高压水化修复；PBS冲洗3次，加一抗，4℃过夜；PBS洗3次，加二抗。室温下DAB显色，苏木精轻度对比染色，并用1%的盐酸乙醇分化5 min、流水冲洗5 min、梯度乙醇脱水（80%、85%、90%、95%、100%、100%）及二甲苯透明，干燥，最后树胶封片。阴性对照为PBS代替一抗。
1.3 Id-1、MMP-9阳性判定标准
Id-1和MMP-9均以细胞质中出现棕黄色颗粒为阳性表达，根据着色细胞占视野细胞总数的百分比及着色细胞染色强弱评分≤5%为0分，5%~25%为1分，＞25%~50%时为2分，＞50%~75%时为3分，＞75%时为4分；阴性：0分；弱（+）：1分；中（++ )：2分；强（+++）：3分。两者相乘，0分为（-），1~4分为（+），5~8分为（++），9~12分为( +++），（+）~（+++）均视为阳性。
1.4 微淋巴管密度检测
应用D-240抗体标记染色于肿瘤微淋巴管内皮细胞的胞质，以孤立的单个棕黄色内皮细胞或内皮细胞簇作为微淋巴管并计数；先在40倍光学显微镜下选出4个脉管最密集的区域（即富集热点区），后换200倍光学显微镜下将着色的内皮细胞区计为观察区，计数取其平均值即为LMVD值。
1.5 统计学方法
运用SPSS17.0统计软件统计并分析数据，用百分率表示计数资料，运用χ2检验表示Id-1和MMP-9的表达与临床病理参数关系，用（x±s）表示计量资料，运用t检验表示LMVD值与临床病理参数的关系，相关性分析采用Spearmen检验，设α=0.05为检验水准。
2 结果
2.1 Id-1和MMP-9在结直肠癌中的表达及LMVD值
Id-1在结直肠癌组织中的阳性表达72.00%（36/50）明显高于癌旁组织24.00%（12/50），两者比较差异有统计学意义（χ2=23.431,P=0.000）； MMP-9在结直肠癌组织中的阳性表达为78%（39/50），明显高于癌旁组织28.00%（14/50），两者比较差异有统计学意义（χ2=18.944,P=0.000）；结直肠癌组织中LMVD表达(15.18±2.16）明显高于癌旁组织（5.24±1.09），两者比较差异有统计学意义（t=25.051,P=0.000），见图 1，表 1。
![]()
图 1 免疫组织化学法检测Id-1、MMP-9在结直肠癌癌旁与癌组织中的表达和LMVDFigure 1 Expression of Id-1,MMP-9 and LMVD in colorectal normal adjacent and colorectal tissues detected by IHC methodA: positive expression of Id-1 in colorectal normal adjacent tissues; B: positive expression of Id-1 in colorectal carcinoma tissues; C : positive expression of MMP-9 in colorectal normal adjacent tissues; D: positive expression of MMP-9 in colorectal carcinoma tissues; E: positive expression of LMVD markd by D-240 in colorectal carcinoma tissues (IHC ×200)表 1 Id-1、MMP-9在结直肠癌癌旁与癌组织中的表达和LMVDTable 1 The expressions of Id-1,MMP-9 and LMVD in colorectal normal adjacent tissues and colorectal carcinoma tissues
2.2 Id-1和MMP-9蛋白的表达水平及LMVD值与临床病理参数间的关系
Id-1、MMP-9表达水平和LMVD均与肿瘤浆膜浸润、TNM分期、淋巴结转移、肝转移、脉管浸润、CEA（+）等相关（均P＜0.01），见表 2。
表 2 Id-1和MMP-9在结直肠癌组织中的表达及LMVD与临床病理因素的关系Table 2 The relationship between the expression of Id-1,MMP-9,LMVD value and clinical pathological parameters in colorectal carcinoma tissues
2.3 Id-1和MMP-9在结直肠腺癌组织中的表达与LMVD的关联
结直肠癌中Id-1阳性者36例，其LMVD值（18.26±3.14）；Id-1阴性者14例，其LMVD值（10.09±3.03），两者比较差异有统计学意义（t=18.511,P=0.000）；结直肠癌中MMP-9阳性者39例，其LMVD值（19.11±3.20）；MMP-9阴性者11例，其LMVD值（9.21±3.05），两者比较差异有统计学意义（t=21.770,P=0.000）。
2.4 Id-1和MMP-9在结直肠癌中表达的相关性
Id-1和MMP-9在结直肠癌中的表达呈明显的正相关关系（r=0.429,P＜0.01），见表 3。
表 3 结直肠癌组织Id-1和MMP-9表达的相关性Table 3 The correlation between the expression of Id-1 and MMP-9 in colorectal carcinoma tissues
3 讨论
Id-1系螺旋-环-螺旋（helix-loop-helix,HLH）转录因子家族重要成员，在正常组织中呈低表达或不表达状态，而在恶性肿瘤及体外培养的肿瘤细胞系中均呈高表达趋势，且与肿瘤的恶性度及患者的预后相关[9]。大多数HLH结构存在一个碱性HLH（bHLH）因子与其紧密相邻，两者相互结合形成异质二聚体，其碱性因子所处区域与目标DNA结合，诱导启动子中的E-盒样结构的靶基因转录并整合成所谓的“E-box”DNA序列，从而调控细胞增殖分化。而Id-1无碱性结构域，与bHLH因子结合生成的二聚体无转录功能，因而无法与目标DNA序列结合，从而抑制细胞分化增殖[10-11]。Cheung等[12]研究报道Id-1表达上调能激活Raf-1及MAPK激酶信号转导途径、抑制细胞凋亡、参与肿瘤发生发展。Lee等[13]研究发现，Id-1还可通过磷酸化抑制Rb途径并阻断p16（INK4a）表达，从而促进G1/S期细胞增殖。
肿瘤的浸润转移是多因素、多步骤参与的复杂过程，其中细胞基质的降解和破坏是肿瘤淋巴道和血行转移的关键步骤。MMP-9作为一种特异性极高血管内皮分裂原，对肿瘤脉管形成及肿瘤恶性生物学行为均有非常重要的影响。Redondo-Munoz等[14]研究显示MMP-9能通过降解细胞外基质使癌细胞呈阿米巴运动方式穿过基质膜缺损处迁移至内皮细胞进入淋巴管腔内，促进淋巴道转移；魏礼清、黄榕权等[15-16]对胰腺癌和浸润性乳腺癌组织研究显示MMP-9能通过裂解细胞外基质，诱导淋巴管内皮细胞迁移从而促进微淋巴管形成，且由于新生淋巴管内皮较薄，基底膜不完整，因而癌细胞易于进入淋巴管道，致淋巴结转移。
本研究显示Id-1和MMP-9在结直肠癌组织中表达明显高于癌旁组织,且与肿瘤的浆膜浸润、TNM分期、淋巴结转移、肝转移及脉管浸润等密切相关,支持Id-1和MMP-9促进肿瘤恶性生物学进展的理论，这与胡斌等[17]研究一致。 LMVD是评价肿瘤微淋巴管生成重要指标，能够准确反映肿瘤微淋巴管生成状况，本实验表明结直肠癌组织中LMVD表达明显高于癌旁组织,同时Id-1和MMP-9在结直肠癌中的表达呈正相关性，且与LMVD亦存在明显的正相关性，进一步说明Id-1和MMP-9在参与结直肠癌变发生发展过程中具有协同作用，Id-1的高异常表达能激活MMP-9，释放促脉管生成的自分泌信号，诱导形成新生的脉管内皮细胞，从而促进肿瘤的淋巴道转移，这与徐健、Georgiadou等[18-19]研究基本一致。且有研究[20]表明 Id-1能通过上调VEGF的表达诱导肿瘤微血管的生成，促进结直肠癌血行转移。Fong等[21]对伴转移的乳腺癌细胞的研究发现抑制Id-1的表达，MT1-MMP表达水平也随之下调，癌细胞的侵袭能力亦明显降低，表明Id-1通过诱导MMP蛋白的表达，诱导微淋巴管形成，发挥促进肿瘤淋巴道转移的作用。
总之，Id-1的异常表达参与结直肠癌的发生演进，并与淋巴结转移等恶性生物学行为密切相关，但本研究仅限于分子蛋白水平，未能从基因水平及其致癌的具体机制进行深入研究，这亦是本课题今后的努力方向。
-
[1] Alexander BM, Othus M, Caglar HB, et al. Tumor volume is a prognostic factor in non-small-cell lung cancer treated with chemoradiotherapy[J]. Int J Radiat Oncol Biol Phys,2011,79(5):1381-7. [2] Basaki K, Abe Y, Aoki M, et al. Prognostic factors for survival in Stage Ⅲ non–small-cell lung cancer treated with definitive radiation therapy: Impact of tumor volume[J]. Int J Radiat Oncol Biol Phys,2006,64(2):449-54. [3] Werner-Wasik M, Swann RS, Bradley J, et al. Increasing tumor volume is predictive of poor overall and progression-free survival: Secondary analysis of the Radiation Therapy Oncology Group 93-11 phase I-II radiation dose-escalation study in patients with inoperable non–small-cell lung cancer[J]. Int J Radiat Oncol Biol Phys,2008,70(2):385-90. [4] Bradley JD, Ieumwananonthachai N, Purdy JA, et al. Gross tumor volume, critical prognostic factor in patients treated with threedimensional conformal radiation therapy for non-small cell lungcarcinoma[J]. Int J Radiat Oncol Biol Phys,2002,52(1): 49-57. [5] Etiz D, Marks LB, Zhou SM, et al. Infl uence of tumor volume on survival in patients irradiated for non-small-cell lung cancer[J].Int J Radiol Oncol Biol Phys,2002,53(4):835-46. [6] Zhu XZ, Wang LH, Zhao LJ, et al. Impact of gross tumor volume and radiation therapy dose on survival in stage III nonsmall- cell lung cancer treated with three dimensional conformal radiation therapy[J].Zhonghua Fang She Zhong Liu Za Zhi, 2008,17(1):26-30.[朱向帜,王绿化,赵路军,等. 局部晚期非小细 胞肺癌三维适形放疗剂量和肿瘤体积与预后关系初探[J]. 中华 放射肿瘤杂志,2008,17(1):26-30.] [7] Shen WB, Zhu SC, Su JW, et al. Analysis of long-term survival in patients treated with three-dimensional conformal radiotherapy for localy advanced non-small cell lung cancer[J]. Zhonghua Fang She Yi Xue Yu Fang Hu Za Zhi, 2010, 30(2):180-5.[沈文斌,祝淑 钗,苏景伟,等. 三维适形放射治疗局部晚期非小细胞肺癌长期 生存分析[J]. 中华放射医学与防护杂志,2010, 30(2):180-5.] [8] Zhao L, West BT, Hayman JA, et al. High radiation dose may reduce the negative effect of large gross tumor volume in patients with medically inoperable early-stage non-small cell lung cancer[J]. Int J Radiat Oncol Biol Phys,2007,68(1):103-10. [9] Le Chervalier T, Arriagada R, Quoix E, et al. Radiotherapy alone versus combined chemotherapy and radiotherapy in nonresectable non-small-cell lung cancer:fi rst analysis of a randomized trial in 353 patients[J]. J Natl Cancer Inst, 1991,83(6):417-23. [10] Dillman RO, Seagren SL, Propert KJ, et al. A randomized trial of induction chemotherapy plus high-dose radiation versus radiation alone in stage III non-small cell lung cancer[J]. N Engl J Med, 1990, 323(14):940-5. [11] Sause WT, Scott C, Taylor S, et al. Radiation Therapy Oncology Group (RTOG) 88-08 and Eastern Cooperative Oncology Group (ECOG) 4588: preliminary results of a phase III trial in regionally advanced, unresectable non-small-cell lung cancer[J].J Natl Cancer Inst,1995,87(3):198-205. [12] Sim S,Bosenzweig KE,Schindelheim R,et al.Induction chemotherapy plus three-dimensional conformal radiation therapy in the defi nitive treatment of locally advanced non-small-cell lung cancer[J].Int J Radiat Oncol Biol Phys,2001,51(3):660-5. [13] Hansen O,Paamp H,Sørensen P,et al. Curative radiotherapy of local advanced non-small-cell lung cancer:eight years of experience from odense[J]. Ugeskr Laeger,2005,167(37):3497- 502. [14] Wang YJ, Wang LH, Wang X, et al. Preliminary results of three-dimensional conformal radiotherapy for non-small cell lung cancer[J]. Zhonghua Fang She Zhong Liu Xue Za Zhi, 2005,4(14):241-4.[王颖杰，王绿化，王鑫，等．91例非小 细胞肺癌三维适形放疗的临床分析[J].中华放射肿瘤学杂志, 2005,4(14):241-4.] [15] Zhan YZ,Huang CJ,Huang JF.Clinical analysis of the effect of concurrent radiochemotherapy on 159 unresectable cases of stage Ⅲ non-small cell lung cancer[J]. Zhongguo Zhong Liu Lin Chuang,2009,36(22):1274-7. [湛永滋,黄昌杰,黄剑峰.159例不宜 手术的Ⅲ期非小细胞肺癌同步放化疗临床分析[J]. 中国肿瘤临 床,2009,36(22):1274-7.] [16] Zhu XZ, Wang LH, Ou GF, et al. Prognosis of locally advanced non-small cell lung cancer treated with three dimensional conformal radiotherapy [J]. Zhonghua Zhong Liu Za Zhi, 2007,29(10):748-53. [朱向帜,王绿化,欧广飞,等. 三维适形放 射治疗局部晚期非小细胞肺癌预后因素分析[J]. 中华肿瘤杂 志,2007,29(10):748-53.] [17] Liu F, Li G, Dang J, et al. Prognostic factor of three dimensional conformal radiation therapy in treating non-small lung cancer[J]. Zhonghua Fang She Zhong Liu Xue Za Zhi, 2007,16(5):344-7. [刘 飞,李光,党军,等.三维适形放疗非小细胞肺癌预后因素分析[J]. 中华放射肿瘤学杂志,2007,16(5):344-7.] [18] Bradley J, Paulus R, Komaki R, et al. A randomized phase III comparison of standard-dose (60 Gy) versus high-dose (74 Gy) conformal chemoradiotherapy +/_ cetuximab for stage IIIa/IIIb non-small cell lung cancer: Preliminary fi ndings on radiation dose in RTOG 0617 (late-breaking abstract 2)[C]. Presented at the 53rd Annual Meeting of the American Society of Radiation Oncology, October 2-6, 2011, Miami, FL.
